- UL Verified Display Anti-discoloration Characteristics
- Resolution : 3,840 × 2,160 (UHD)
- Brightness : 3,000 nit (Typ.), 2,800 nit (Min.)
- Portrait / Landscape
- Slim Design
- Conformal Coating
LG Open Frame display empowers you to personalize not only the casing design but also the function, granting you the flexibility to tailor the digitial signage frame to your exact preferences.
By focusing on the pain points of our customers, we obtained the world’s first UL Verification for Display Anti-Discoloration Characteristics. Our new technology helps prevent ‘screen-yellowing’, while maintaining display quality and performance stability.
With outstanding high brightness of 3,000 nits (Typ.), the XF3PS outdoor open frame display delivers content clearly while captivating passerby. In addition, its outdoor visibility can deliver a variety of information even to those wearing polarized sunglasses.
| Display | |
|---|---|
| Screen size | 75" |
| Display technology | IPS, M+ |
| Native aspect ratio | 16:9 |
| Display resolution | 3840 x 2160 pixels |
| HD type | Ultra HD (UHD) |
| Native refresh rate | 60 Hz |
| Brightness | 3,000 nits (Typ.), 2,800 nits (Min.) |
| Contrast ratio | 1,200:1 |
| Dynamic contrast ratio | 500,000:1 |
| Viewing angle (horizontal) | 178° |
| Viewing angle (vertical) | 178° |
| Display colours | 1.07 billion colours |
| Colour depth | 10 bit |
| Response time | 8 ms (G to G) |
| Colour gamut | 68% NTSC |
| Surface treatment | 3% haze |
| Panel lifetime | 50,000 hours |
| Operating hours | 24 / 7 |
| Portrait / Landscape | Yes / Yes |
| QWP (Quarter Wave Plate) | Yes |
| Design | |
| Product colour | Black |
| Bezel width | 11.8 mm |
| VESA mounting | No |
| Display type | Open Frame |
| Smart Signage | |
| Operating system | webOS 6.1 |
| Internal memory | 8 GB |
| Embedded CMS | Yes |
| Local contents scheduling | Yes |
| Group Manager | Yes |
| USB Plug & Play | Yes |
| Fail Over | Yes |
| Background image | Yes |
| Video Tag | 2 |
| Play via URL | Yes |
| Screen rotation | Yes |
| External input rotation | Yes |
| Gapless playback | Yes |
| Tile mode | Yes, max. 15 x 15 |
| Setting data cloning | Yes |
| SNMP | Yes |
| ISM method | Yes |
| Auto Set ID | Yes |
| Status mailing | Yes |
| Control Manager | Yes |
| Smart Energy Saving | Yes |
| PM mode | Yes |
| Wake on LAN | Yes |
| Network Ready | Yes |
| HDMI-CEC | Yes |
| SI Server Setting | Yes |
| webRTC | Yes |
| Pro:Idiom | Yes |
| Brightness Compensation | Yes |
| Sensors | |
| Temperature sensor | Yes |
| Auto brightness sensor | Yes |
| Current sensor | Yes |
| BLU sensor | Yes |
| Humidity sensor | Yes |
| Local key operation | Yes |
| Fan | Yes, built-in |
| Special Features | |
| Conformal coating | Power board |
| Power protection | Yes |
| Direct sunlight | Yes |
| Anti-discoloration characteristics | UL Verified |
| Smart brightness compensation | Yes |
| Vandalism alert | Yes |
| Connectivity | |
| HDMI inputs | 2 |
| HDMI HDCP version | 2.2 |
| DisplayPort input | Yes, HDCP 1.3 |
| DisplayPort output | Yes |
| RS-232C input | Yes |
| RS-232C output | Yes |
| Ethernet LAN (RJ-45) input | Yes |
| USB 2.0 ports | 1 |
| External speaker output | Yes, L/R 10 W + 10 W |
| IR output | Yes |
| Audio | |
| Built-in speakers | No |
| External speaker output power | 10 W + 10 W |
| Environment | |
| Operating temperature | 0 °C to 50 °C (without direct sunlight); 0 °C to 40 °C (with direct sunlight) |
| Operating humidity | 10% to 80% |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power supply type | Built-in power |
| Typical power consumption | TBD |
| Maximum power consumption | TBD |
| DPM power consumption | TBD |
| Power consumption (power off) | 0.5 W or less |
| BTU | TBD |
| Weight & Dimensions | |
| Width | 1675.2 mm |
| Height | 953.6 mm |
| Depth | 128.9 mm |
| Weight | 37.5 kg |
| Package weight | 47.0 kg |
| Certifications | |
| Safety certification | CB / NRTL |
| EMC certification | FCC Class A / CE / KC / VCCI |
| ErP | Yes |
| ePEAT | No (US only) |
| Software Compatibility | |
| SuperSign CMS | Yes |
| SuperSign Control+ | Yes |
| SuperSign Cloud | Yes |
| ConnectedCare | Yes |
| Accessories | |
| Remote controller | Yes, including 2 batteries |
| HDMI cable | Yes |
| USB cables | 2 |
| Manual | Yes |
| Regulation book | Yes |
| Phone to RS-232C gender | Yes |
| LAN extension cables | 2 |
| SMA cables | 2 |
| IR cable | Yes |
| JCD 5P PWR cables | 3 |
| JCD 8P PWR cable | 1 |
| Cord grip rubber | 5 |
| Screws | 6 |
| JCD corner brackets | 4 |
