- UL Verified Display Anti-discoloration characteristics
- Resolution : 1,920 × 1,080 (FHD)
- Brightness : 4,000 nits (Typ.), 3,200 nits (Min.)
- Temperature Sensor
- Auto Brightness Sensor
- Support HDBaseT
LG provides advanced technical solutions equipped with various sensors, offering reliable and effective operations. Even in diverse environments exposed to sunlight, the XE4P-M can enhance your content visibility while alleviating concerns about excessive operational burdens. Designed to fit existing legacy casings, it provides a convenient replacement option. Now is the time to embrace the new standard in outdoor displays.
With outstanding high brightness of 4,000 nits (Typ.), the XE4P-M delivers content clearly, captivating passersby. Thanks to IPS technology, viewers can engage with the content from wide viewing angles. Additionally, M+ Color Settings applied to the panel enhances picture color quality, showcasing content vividly for onlookers.
By focusing on the key pain points, we developed our new "Anti-Discoloration" technology designed to deter both screen yellowing and black circles. With an enhanced thermal solution, the XE4P-M can deliver long-lasting and stable display quality.
| Display | |
|---|---|
| Screen size | 49" |
| Panel technology | IPS, M+ |
| Backlight type | Direct |
| Native aspect ratio | 16:9 |
| Display resolution | 1920 x 1080 pixels |
| HD type | Full HD |
| Native refresh rate | 60 Hz |
| Brightness | 4,000 nits (Typ.), 3,200 nits (Min.) |
| Contrast ratio | 1,300:1 |
| Dynamic contrast ratio | 500,000:1 |
| Viewing angle (horizontal) | 178° |
| Viewing angle (vertical) | 178° |
| Display colours | 1.07 billion colours |
| Colour depth | 10 bit |
| Response time | 8 ms (G to G) |
| Surface treatment | 3% haze |
| Colour gamut | 67% |
| Panel lifetime | 50,000 hours |
| Operating hours | 24/7 |
| Portrait / Landscape | Yes / Yes |
| QWP (Quarter Wave Plate) | Yes |
| Protection Glass | |
| Glass thickness | 5 mm |
| Degree of protection | IK10 |
| Glass type | Tempered |
| Anti-reflective | Yes |
| Infrared resistance | Yes |
| Shatter-proof | Yes |
| Smart Signage | |
| Operating system | webOS 6.1 |
| Internal memory | 16 GB eMMC |
| Wi-Fi / Bluetooth built-in | Yes |
| Local contents scheduling | Yes |
| Group Manager | Yes |
| USB Plug & Play | Yes |
| Fail Over | Yes |
| Booting Logo Image | Yes |
| No Signal Image | Yes |
| RS-232C Sync | Yes |
| Local Network Sync | Yes |
| Backlight Sync | Yes |
| PIP | Yes |
| PBP | Yes, 2 |
| Video Tag | Yes, 4 |
| Play via URL | Yes |
| Screen rotation | Yes |
| External input rotation | Yes |
| Gapless playback | Yes |
| Tile mode | Yes, max. 15 x 15 |
| Setting data cloning | Yes |
| SNMP | Yes |
| ISM method | Yes |
| Auto Set ID | Yes |
| Status mailing | Yes |
| Control Manager | Yes |
| Smart Energy Saving | Yes |
| PM mode | Yes |
| Wake on LAN | Yes |
| Network Ready | Yes |
| Beacon | Yes |
| HDMI-CEC | Yes |
| SI Server Setting | Yes |
| webRTC | Yes |
| Pro:Idiom | Yes |
| Sensors | |
| Temperature sensor | Yes |
| Auto brightness sensor | Yes |
| Pixel sensor | Yes |
| Current sensor | Yes |
| BLU sensor | Yes |
| Humidity sensor | Yes |
| Acceleration (Gyro) sensor | Yes |
| Power indicator | Yes |
| Fan | Yes, built-in |
| Design | |
| Bezel colour | Black |
| Bezel width | 38.4 / 26 / 26 / 38.4 mm |
| VESA mounting | No |
| Connectivity | |
| HDMI inputs | 2 |
| HDMI HDCP version | 2.2 |
| DisplayPort input | Yes, HDCP 2.2 |
| RS-232C input | Yes, 4-pin phone jack |
| Ethernet LAN (RJ-45) input | 2, LAN + HDBaseT |
| USB 2.0 ports | 2 |
| RS-232C output | Yes |
| Ethernet LAN (RJ-45) output | Yes |
| External speaker output | Yes, L/R 10 W + 10 W |
| Audio | |
| Built-in speakers | No |
| External speaker output | L/R 10 W + 10 W |
| Environment | |
| Operating temperature | -30 °C to 50 °C |
| Operating humidity | 5% to 100% |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power supply type | Built-in |
| Typical power consumption | 190 W |
| Maximum power consumption | 400 W |
| Smart Energy Saving (70%) | 160 W |
| DPM power consumption | Under 0.5 W |
| Power consumption (power off) | Under 0.5 W |
| Typical BTU | 1,024 BTU/Hr |
| Maximum BTU | 1,194 BTU/Hr |
| Mechanical | |
| Width | 1,153 mm |
| Height | 656.2 mm |
| Depth | 88 mm |
| Weight | 31.2 kg |
| Package width | 1,287 mm |
| Package height | 797 mm |
| Package depth | 207 mm |
| Package weight | 36.2 kg |
| Certifications | |
| Safety certification | CB / NRTL |
| EMC certification | FCC Class A / CE / KC / VCCI |
| ErP | Yes |
| Software Compatibility | |
| SuperSign CMS | Yes |
| SuperSign Control+ | Yes |
| SuperSign Cloud | Yes |
| LG ConnectedCare | Yes |
| Special Features | |
| Tilt (Face down) | Yes, +15° |
| IP rating | IP56 |
| Direct sunlight | Yes |
| Conformal coating | Yes, power board |
| Heat dissipation | Heat exchange |
| Noise level | Under 62 dB |
| Accessories | |
| Remote controller | Yes |
| Manual | Yes |
| Regulation book | Yes |
| Phone to RS-232C gender | Yes |
| HDMI cable | Yes |
| Power cable | Yes |
| Batteries | Yes |
| Screws | Yes |
| Language | |
| OSD languages | English, French, German, Spanish, Italian, Korean, Chinese (Simplified), Chinese (Traditional), Portuguese (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portuguese (Europe), Dutch, Czech, Greek, Turkish, Polish, Arabic |
